Product features

1. with electrical knife function, user-independent realization of a key knife.
2. High sensitivity sensor, good linearity, durable and reliable
3. The cutting motor is a servo motor, which can set the cutting speed for different materials.
4. The calibration function is open to the user, and the calibration result system can judge automatically.
5. Calibration measurement principle, high precision, allowing high initial unbalance
6. Belt drive structure, high measurement accuracy, more convenient to use
7. Advanced electronic measurement system, friendly HMI, easy to operate
8. Modular design, wide application range

Technical Specifications

• model：YNQ40P-A1
• Weight of workpiece (max)：5-50kg
• Max diameter：ф100-ф200mm
• Drive mode：Belt drive
• spacing-between-supports：50-500mm
• rotor-overlap-thickness：100-280mm
• rotor-shaft-diameter：20-60mm
• Min.achievable residual unbalance：0.1g.mm/kg
• one-time-weiahtremoval-rate：≥90%
• Unbalance reduction ratio：≥95%
